LIGHT SOURCE CUDA XLS-180
LIGHT SOURCE CUDA XLS-180
Fr735 (CHF)
or
Call + 41 (0)27 720 41 00
Description
SPECIFICATION
- Light guide adapter: Turret type for your choice of four: Storz, ACMI, Pentax, Wolf, Olympus
- Brightness control: Mechanical iris control from front panel
- Regulatory approvals: UL60601, EN 60601-1, EN 60601-1-2, CAN / CSA, C22.2
Operating environment
Storage environment
Specifications
| Condition | Used |
| Stock Number | 7391 |
| Lamp type | Cermax 175-watt xenon type |
| Power | 175 watts |
| Temperature | 5600 K |
| Duration | 650 hours |
| Lamp replacement | on the side of the unit |
| Input voltage | 100-120V AC, 50/60 Hz, 220-240V AC, 50 Hz |
| Energy consumption | 250 watts max |
| Equipment class | Type BF |
| Operating mode | Continuous operation |
| Water-resistant | Unprotected equipment, IPX0 |
| The temperature | -20 ° to + 60 ° C (-4 ° to 140 ° F) |
| Relative humidity | 0 à 95% |
| Atmospheric pressure | 700 to 1060 hPa |
| Dimensions | 355 (14) W x 130 (5) H x 250 (10) D mm |
| The weight | 9.5 lb / 4.3 kg |
